| Category | Specification |
|---|
| Engine | |
| Engine Make & Model | Perkins 404J-E22TA (Turbo) |
| Gross Horsepower | 67 hp (50.0 kW) |
| Net Horsepower | 64 hp (47.7 kW) |
| Peak Torque | 208 Nm @ 1800 rpm |
| Displacement | 2.2 L |
| Emissions Compliance | Tier 4 Final / EU Stage V |
| Performance | |
| Rated Operating Capacity | 1,750 lb (790 kg) |
| Tipping Load | 3,500 lb (1,588 kg) |
| ROC with Counterweights | 1,840 lb (835 kg) |
| Breakout Force (Lift) | 17.0 kN |
| Breakout Force (Bucket) | 32.3 kN |
| Hydraulics | |
| Standard Flow | 20.6 gpm (78.0 L/min) @ 3,050 psi (210 bar) |
| High Flow (Optional) | 30.7 gpm (116.2 L/min) @ 3,050 psi (210 bar) |
| Dimensions | |
| Height to Hinge Pin | 3,099 mm |
| Overall Height | 1,974 mm |
| Length without Attachment | 2,685 mm |
| Length with Bucket | 3,305 mm |
| Overall Width | 1,642 mm |
| Wheelbase | 1,128 mm |
| Ground Clearance | 178 mm |
| Dump Height | 2,470 mm |
| Dump Reach @ Max Height | 542 mm |
| Dump Angle | 40° |
| Rollback Angle (Ground) | 32° |
| Departure Angle | 23° |
| Weights | |
| Operating Weight | 2,842 kg |
| Shipping Weight | 2,705 kg |
| Travel Speeds | |
| Low Range | 11.9 km/h |
| High Range (Optional) | 18.5 km/h |
| Fuel & Service | |
| Fuel Tank Capacity | 73.8 L |
| Hydraulic Reservoir | 18.9 L |
| Hydraulic System Capacity | 32.2 L |
| Standard Features | |
| Lift Geometry | Radial |
| ROPS/FOPS Level 1 | Included |
| Manual Attachment Coupler | Included |
| LED Work Lights | 2 front, 2 side, 2 rear |
| CASE SiteWatch™ Telematics | 5-year subscription |
| Optional Features | |
| High-Flow Hydraulics | 30.7 gpm (116.2 L/min) |
| Hydraulic Attachment Coupler | Available |
| Electro-Hydraulic Controls | Available |
| Deluxe Air Suspension Seat | Heated with lumbar support |
| 8-inch LCD Display | Available |
| Ride Control | Available |
| Creep Speed Mode | Available |
