| Category | Specification |
|---|---|
| Engine | |
| Engine Model | Doosan 4-cylinder, Stage V compliant |
| Displacement | 3400–3409 cm³ |
| Rated Power | 90 HP (66.2 kW) at 2600 rpm |
| Max Torque | 410–430 Nm at 1700 rpm |
| Emission Standard | Stage V |
| Cooling System | Water-cooled with turbocharger and intercooler |
| Fuel Tank Capacity | 135–145 L |
| AdBlue Tank Capacity | 15.6 L |
| Transmission & Drive | |
| Drive Type | 4WD (electrohydraulically activated) |
| Transmission | Mechanical, synchronized with mechanical reverse |
| Gears | 18 forward + 18 reverse |
| Differential Lock | Electro-hydraulic controlled |
| Max Speed | 40 km/h |
| Hydraulics & PTO | |
| Hydraulic Pump Flow Rate | 245 + 16 L/min |
| Hydraulic Outlets | 4 pcs EURO |
| Lift Capacity | 2800 kg (closest to tractor), 1400 kg at 610 mm |
| PTO | Rear 540/1000 rpm, electro-hydraulic connected |
| Dimensions & Weight | |
| Length | 4725 mm |
| Width | 2200 mm |
| Height | 3185 mm |
| Ground Clearance | 430 mm |
| Wheelbase | 2370 mm |
| Front/Rear Track Width | 1660–1720 mm |
| Weight with Cab | 5000 kg |
| Tires | |
| Front Tires | 380/70R24 |
| Rear Tires | 520/70R34 |
| Cabin & Features | |
| Cabin | Air-conditioned and heated, GRAMMER seat, radio with USB and speakers |
| Steering | Hydrostatic with power steering |
| Brake System | Disc in oil bath, brake on 4 wheels (additionally braked front axle) |
| Towing Brake System | Air |
| Clutch | Dry, 1-stage, 1-disc |
